Lennox XC16 User Manual

XC16 - 2 to 5 Ton Heat Pump / Page 17
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC16-048-230 + TXV 45,500 14.70 11.50 C33-48 G71MPP-60C-090 3145298
XC16-048-230 + TXV 45,500 14.50 11.50 C33-48 G71MPP-60C-110 1488410
XC16-048-230 + TXV 47,500 15.50 12.20 C33-49 G60UHV-60C-090 1003772
XC16-048-230 + TXV 47,500 15.50 12.20 C33-49 G60UHV-60C-110 1003773
XC16-048-230 + TXV 47,500 15.20 12.00 C33-49 G61MPV-60C-090 1003774
XC16-048-230 + TXV 47,500 15.00 12.00 C33-49 G61MPV-60C-110 1003775
XC16-048-230 + TXV 46,500 14.70 11.70 C33-49 O23V5-140/154 1038250
XC16-048-230 + TXV 47,000 14.20 11.70 C33-49 1003730
XC16-048-230 + TXV 47,500 15.00 11.70 C33-49 G61MPV-60C-091 1046654
XC16-048-230 + TXV 47,000 15.00 11.70 C33-49 G61MPV-60C-111 1046655
XC16-048-230 + TXV 47,500 15.20 12.00 C33-49 G71MPP-60C-090 3145301
XC16-048-230 + TXV 47,500 15.00 12.00 C33-49 G71MPP-60C-110 1488403
XC16-048-230 + TXV 46,500 15.20 11.70 C33-50/60C G60UHV-60C-090 1003769
XC16-048-230 + TXV 46,500 15.00 11.70 C33-50/60C G60UHV-60C-110 1003759
XC16-048-230 + TXV 46,000 15.00 11.70 C33-50/60C G61MPV-60C-090 1003766
XC16-048-230 + TXV 46,000 14.70 11.70 C33-50/60C G61MPV-60C-110 1003768
XC16-048-230 + TXV 46,000 14.50 11.20 C33-50/60C O23V5-140/154 1038251
XC16-048-230 + TXV 46,500 13.70 11.20 C33-50/60C 1003726
XC16-048-230 + TXV 46,000 15.20 11.20 C33-50/60C CBWMV-60C-100 1088641
XC16-048-230 + TXV 46,000 14.70 11.50 C33-50/60C G61MPV-60C-091 1046656
XC16-048-230 + TXV 46,000 14.70 11.70 C33-50/60C G61MPV-60C-111 1046657
XC16-048-230 + TXV 46,000 15.00 11.70 C33-50/60C G71MPP-60C-090 3145296
XC16-048-230 + TXV 46,000 14.70 11.70 C33-50/60C G71MPP-60C-110 1488402
XC16-048-230 + TXV 47,000 15.70 12.20 C33-60D G60UHV-60D-135 1003982
XC16-048-230 + TXV 46,500 15.00 11.50 C33-60D O23V5-140/154 1003981
XC16-048-230 + TXV 46,500 14.00 11.50 C33-60D 1004000
XC16-048-230 + TXV 47,000 15.50 12.20 C33-60D G61MPV-60D-135 3133211
XC16-048-230 + TXV 48,000 15.70 12.30 C33-62C G60UHV-60C-090 1003980
XC16-048-230 + TXV 48,000 15.70 12.20 C33-62C G60UHV-60C-110 1003979
XC16-048-230 + TXV 48,000 15.70 12.20 C33-62C G61MPV-60C-090 1003978
XC16-048-230 + TXV 47,500 15.20 12.00 C33-62C O23V5-140/154 1003977
XC16-048-230 + TXV 47,500 14.20 11.70 C33-62C 1003996
XC16-048-230 + TXV 48,000 15.50 12.00 C33-62C G61MPV-60C-091 1046658
XC16-048-230 + TXV 48,000 15.50 12.30 C33-62C G61MPV-60C-111 1046659
XC16-048-230 + TXV 48,000 15.50 12.30 C33-62C G71MPP-60C-090 3145297
XC16-048-230 + TXV 47,500 15.70 12.50 C33-62D G60UHV-60D-135 1003976
XC16-048-230 + TXV 47,000 15.20 12.00 C33-62D O23V5-140/154 1003975
XC16-048-230 + TXV 47,000 14.20 11.50 C33-62D 1003997
XC16-048-230 + TXV 48,000 14.70 11.70 CB26UH-042 1003995
XC16-048-230 + TXV 48,000 14.70 11.70 CB26UH-042-R 1186491
XC16-048-230 + TXV 48,000 14.70 12.00 CB26UH-048 1003952
XC16-048-230 + TXV 48,000 14.70 12.00 CB26UH-048-R 1186489
NOTES:
+ TXV = Matched with Thermostatic Expansion Valve.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see TXV Substitutions Table.

Lennox XC16 Specifications

General

SEER Rating	Up to 17.20
Cooling Capacity	1.5 to 5 tons
Sound Level	As low as 72 dB
Energy Star Certified	Yes
Refrigerant	R-410A
Warranty	10-Year Limited Warranty on compressor and parts
Compressor	Single-stage
