Page 35
XP16
Table 1 − HFC−410A Normal Operating Pressures (Liquid +10 & Suction +5 psig) (XP16−XXX−230−05)
Size −024 −036 −048 −060
Model XP16 Only XP16 and SPB*H4
F (C) Liq Vap Liq Vap Liq Vap Liq Vap
Normal Operating Pressures − Cooling
First Stage (Low Capac-
ity) Pressure
65 (18.3) 226 144 220 141 224 143 230 137
75 (23.9) 260 145 254 144 259 143 267 139
85 (29.4) 301 148 295 148 302 147 311 141
95 (35.0) 346 151 340 150 346 149 357 144
105 (40.6) 396 153 389 153 396 152 398 147
115 (46.1) 451 156 444 156 450 155 453 149
Second Stage (High Ca-
pacity) Pressure
65 (18.3) 241 140 232 129 238 138 232 131
75 (23.9) 279 142 269 136 278 140 276 133
85 (29.4) 321 144 312 140 321 142 320 136
95 (35.0) 369 146 346 142 372 144 367 138
105 (40.6) 421 148 409 145 424 147 421 141
115 (46.1) 480 151 465 148 481 149 479 144
Normal Operating Pressures − Heating
First Stage (Low Capac-
ity) Pressure
50 (10) 312 112 350 115 336 114 385 108
60 (15.5) 330 130 372 136 363 135 414 126
Second Stage (High Ca-
pacity) Pressure
20 (−7.0) 299 64 321 61 289 57 332 59
30 (−1.0) 312 79 347 74 294 69 349 67
40 (4.4) 325 93 367 90 321 80 361 75
50 (10) 344 110 387 110 341 110 383 85
60 (15.5) 358 128 395 131 361 128 425 122
