Lennox XP21 Series User Manual

Page 3
XP17
Model Number
Unit Outdoor Fan
Sound Rating Number
(dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter - inches.
XP17-048-230-01, -02, -03, -04, 05, -06 71 14 lbs. 0 oz. 5 26.2
XP17-048-230-07 73 14 lbs. 0 oz. 5 26.2
XP17-048-230-08 73 13 lbs. 10 oz. 5 26.2
Model Number
Unit Outdoor Fan
Sound Rating Number
(dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter - inches.
XP17-060-230-01, -02, -03, -04, 05, -06,
-07
73 14 lbs. 8 oz. 5 26.2
XP17-060-230-08 73 14 lbs. 2 oz. 5 26.2
1
Tested according to AHRI Standard 270-2008 test conditions.
2
Refrigerant charge sufficient for 15 feet length of refrigerant lines.
Electrical Data
208/230V-60 Hz-1 Ph
Model Number
Unit Compressor Condenser Fan
Maximum Over-
current Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated Load
Amps (RLA)
Locked
Rotor Amps
(LRA)
Motor HP Nominal RPM
Full Load
Amps (FLA)
XP17-024-230-01, -02,
-03, -04
30 18.9 13.5 58.3 1/3 400 2.0
XP17-024-230-05, -06,
-07. -08
30 20.0 13.5 58.3 1/3 400 2.0
208/230V-60 Hz-1 Ph
Model Number
Unit Compressor Condenser Fan
Maximum Over-
current Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated Load
Amps (RLA)
Locked
Rotor Amps
(LRA)
Motor HP Nominal RPM
Full Load
Amps (FLA)
XP17-030-230-01, -02,
-03, -04
30 19.6 14.1 73.0 1/3 450 2.0
XP17-030-230-05, -06 30 20.0 14.1 73.0 1/3 450 2.0
XP17-030-230-07 30 20.4 14.1 73.0 1/3 450 2.0
XP17-030-230-08, -09 30 20.0 14.1 73.0 1/3 450 2.0
208/230V-60 Hz-1 Ph
Model Number
Unit Compressor Condenser Fan
Maximum Over-
current Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated Load
Amps (RLA)
Locked
Rotor Amps
(LRA)
Motor HP Nominal RPM
Full Load
Amps (FLA)
XP17-036-230-01, -02,
-03, -04, -05, -07, -08
35 22.9 16.7 79.0 1/3 600 2.0
208/230V-60 Hz-1 Ph
Model Number
Unit Compressor Condenser Fan
Maximum Over-
current Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated Load
Amps (RLA)
Locked
Rotor Amps
(LRA)
Motor HP Nominal RPM
Full Load
Amps (FLA)
XP17-042-230-01, -02,
03, -04, -05, -07, -07,
-08
40 24.4 17.9 107.0 1/3 600 2.0
208/230V-60 Hz-1 Ph
Model Number
Unit Compressor Condenser Fan
Maximum Over-
current Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated Load
Amps (RLA)
Locked
Rotor Amps
(LRA)
Motor HP Nominal RPM
Full Load
Amps (FLA)
XP17-048-230-01, -02,
-03, -04, -05, -06, -07,
-08
50 29.3 21.8 117.0 1/3 675 2.0
