Page 51
XP17
XC21 iComfort™ Outdoor Unit
Wiring Detail with Utility Load Shedding - Alternate Wiring Method
Outdoor Control Part Numbers
103369-01
103369-02
NOTE: This alternate wiring method is not applicable to early production XC17, XP17, XC21 and XP21 outdoor
units that used outdoor control 101796xx, 101797xx, 101798xx and 101799xx.
Utility Load Control Receiver
Contacts (N.C. contacts shown,
verify contact configuration)
Compressor
Contactor
Remove existing wire
to contactor coil.
Figure 28. Non-Preferred Method - Outdoor Control- 103369-01 and 103369-02 Only)
