4.2.4 Connecting MiniCODER electrically
Pay attention to the minimum bending radius so that the connection cable
is not damaged by excessive bending (→ document Technical informa-
tion).
 Observe the instructions on electromagnetic compatibility while laying the cables
(→ page 33).
 Correctly connect the MiniCODER as per the pin layout (→ document Technical
information).
