1040 Bluetooth daughter card (BDC)
For access, remove these FRUs in order:
v “1010 Battery pack” on page 46
v “1020 Hard disk drive slot cover” on page 47
2
1
3
Step Screw (quantity) Color Torque
1 M2 × 4 mm, flat-head, nylon-coated (1) Black 0.245 Nm
(2.5 kgfcm)
When installing: Make sure that the connector is attached firmly.
Removing and replacing a FRU
48 MT 8922
