1080 DIMM
For access, remove these FRUs in order:
v “1010 Battery pack” on page 46
v “1070 DIMM slot cover” on page 51
1
1
2
When installing: Insert the notched end of the DIMM into the socket. Press the
DIMM firmly, and pivot it until it snaps into the place. Make
sure that it is firmly fixed in the slot and does not move easily.
Removing and replacing a FRU
52 MT 8922
