Lenovo 5106 User Manual

Installingabattery
Toinstallabattery,dothefollowing:
1.Turnoffthecomputer.
2.Disconnectallcables,powercords,andexternaloptionsfromyourcomputer.See“Locatingconnectors
ontherearofyourcomputer”onpage68.
3.Placeasoft,cleantowelorclothonthedeskorsurface.Holdthesidesofyourcomputerandgentlylay
itdownsothatthescreenisagainstthesurfaceandthecoverisfacingup.
4.Removethecomputercover.See“Removingthecomputercover”onpage74.
5.Openthesystemboardshielding.See“Openingthesystemboardshielding”onpage75.
6.Tiltthebatterysothatyoucaninsertitintothesocketonthesideoppositethebatteryclip.
7.Pressthebatterydownintothesocketuntilitclicksintoplace.Makesurethatthebatteryclipholdsthe
batterysecurely.
8.Closethesystemboardshielding.See“Closingthesystemboardshielding”onpage76.
9.Goto“CompletingtheFRUinstallation”onpage109.
Replacingthepowersupplyassembly
Attention
Neverremovethecoveronapowersupplyoranypartthathasthefollowinglabelattached.
Hazardousvoltage,current,andenergylevelsarepresentinsideanycomponentthathasthislabelattached.
Therearenoservicablepartsinsidethesecomponents.
Attention:
Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“ImportantSafety
Information”onpage1.
Thissectionprovidesinstructionsonhowtoreplacethepowersupplyassembly.
Removingthepowersupplyassembly
Toremovethepowersupplyassembly,dothefollowing:
1.Turnoffthecomputer.
Chapter9.ReplacingFRUs101
