•Wi-Fiantennaslot
UsedtoinstalltherearWi-Fiantennacableconnectorthatisoptional.TherearWi-Fiantennaisinstalled
ontherearWi-Fiantennacableconnector.
Computercomponents
Note:Someofthefollowingcomponentsareoptional.
Figure3.Computercomponents
1Computercover
2Powersupplyassembly
3Opticaldrive4Storagedrive(a2.5-inchor3.5-inchstoragedrive)
5FrontaudioandUSBassembly6Cardreader
7Battery8FrontWi-Fiantenna
9Thermalsensor
10Frontfan
11Memorymodules12Microprocessor
13M.2Wi-Ficardslot
14PCIExpresscard
15RearWi-Fiantenna
16Systemboard
30ideacentre510SHardwareMaintenanceManual
