Hardware Replacement Guide
4. Pushthecomputerstandupwardtotheend , then slide the lock to the right
side to lock the computer stand
.
1
2
5. Remove the 2 screws that secure the computer stand to the computer
chassis.
6. Slide out the computer stand.
4
3
3
Warning:
When finish replacing a CRU, follow the instructions below to install back
computer stand. Incorrect operations may damage the computer stand.
