Hardware Replacement Guide
Rear view
The following illustration shows the location of connectors on the rear of the
computer.
2
1
3
4
6
5
7
Powerconnector TV tuner connector (selected models)
PS/2keyboardconnector USBports(4)
IEEE1394connector Wireless reset button
Ethernet connector
