Figure 56. Remove the RTC battery

Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement

part:

RTC battery

Remove the Microphone module

Make sure the following FRUs (or CRUs) have been removed.

“Remove the lower case” on page 50

“Remove the battery pack” on page 53

“Remove the hard disk drive (HDD) module” on page 54

Step 1. Disconnect the microphone board cable from the system board and then remove the microphone

board.

Figure 57. Remove the microphone board

Step 2. Remove the microphone board cable.

Figure 58. Remove the microphone board cable

Chapter 4. Removing a FRU or CRU 59
