Chapter6.Replacingdevices

Thischapterprovidesinstructionsonhowtoinstallorreplacehardwareforyourcomputer.

•“Staticelectricityprevention”onpage67

•“Replacingthebattery”onpage67

•“ReplacingtheSIMcard”onpage69

•“Replacingtheharddiskdrive”onpage70

•“Replacingtheopticaldrive”onpage73

•“ReplacingaPCIExpressMiniCardforwirelessLANconnection”onpage77

•“ReplacingaPCIExpressMiniCardforwirelessWANconnection”onpage80

•“Replacingamemorymodule”onpage85

•“Replacingthekeyboard”onpage87

•“Replacingthebackupbattery”onpage92

•“Replacingthethermalfan”onpage95

Staticelectricityprevention

Staticelectricity,althoughharmlesstoyou,canseriouslydamagecomputercomponentsandoptions.

Improperhandlingofstatic-sensitivepartscancausedamagetothepart.Whenyouunpackanoptionor

aCRU,donotopenthestatic-protectivepackagecontainingthepartuntiltheinstructionsdirectyou

toinstallit.

WhenyouhandleoptionsorCRUs,orperformanyworkinsidethecomputer,takethefollowingprecautions

toavoidstatic-electricitydamage:

•Limityourmovement.Movementcancausestaticelectricitytobuilduparoundyou.

•Alwayshandlecomponentscarefully.Handleadapters,memorymodules,andothercircuitboardsbythe

edges.Nevertouchexposedcircuitry.

•Preventothersfromtouchingcomponents.

•Whenyouinstallastatic-sensitiveoptionorCRU,touchthestatic-protectivepackagecontainingthe

parttoametalexpansion-slotcoverorotherunpaintedmetalsurfaceonthecomputerforatleasttwo

seconds.Thisreducesstaticelectricityfromthepackageandyourbody.

•Whenpossible,removethestatic-sensitivepartfromthestatic-protectivepackagingandinstallthepart

withoutsettingitdown.Whenthisisnotpossible,placethestatic-protectivepackagingonasmooth,

levelsurfaceandplacethepartonit.

•Donotplacethepartonthecomputercoverorothermetalsurface.

Replacingthebattery

Beforeyoustart,printtheseinstructions.

ThissystemsupportsonlybatteriesspeciallydesignedforthisspecicsystemandmanufacturedbyLenovo

oranauthorizedbuilder.Thesystemdoesnotsupportunauthorizedbatteriesorbatteriesdesignedforother

systems.Ifanunauthorizedbatteryorabatterydesignedforanothersystemisinstalled,thesystemwill

notcharge.
