3USB3.0connectorwithbatterychargingfunction
TheUSB3.0connectorwithbatterychargingfunctionisusedtodothefollowing:
•ConnectingUSBdevices(USB1.0,USB1.1,USB2.0,andUSB3.0compatible)
•Chargingdevicesevenwhenyournotebookcomputeristurnedoff,insleepmode,orinhibernation
mode;orwhenthedockisdisconnectedfromyournotebookcomputer
4USB3.0connector
TheUSB3.0connectorisusedtoconnectUSBdevices(USB1.0,USB1.1,USB2.0,andUSB3.0
compatible).
5Security-lockslot
Thesecurity-lockslotisusedtosecurethedockwithasecuritycablelock.
Note:Thesecuritycablelockisnotincludedinyouroptionpackage.Ifnecessary,purchaseasecurity
cablelock.
6OneLinkcable
TheOneLinkcableisusedtoconnectthedocktoyournotebookcomputer.
Note:Toavoidanyfiredamage,ensurethatthenotebookcomputerconnectingtheOneLinkcablemeets
eitherofthefollowingrequirements:
•TheflammabilityofthenotebookcomputerenclosureisnotlowerthanClassV-1.
•Thenotebookcomputerenclosureismetallic.
7Cablemanagementstand
ThecablemanagementstandisusedtomanagetheOneLinkcabletooptimizedeskspace.
8Powerconnector
Thepowerconnectorisusedtoconnectthepoweradapter.
Note:Thepowerinputratingofthedockis20Vand4.5A.
9GigabitEthernetconnector
TheGigabitEthernetconnectorisusedtoconnectthedocktoanetworkusinganEthernetcable.
10USB3.0connectors
ThetwoUSB3.0connectorsareusedtoconnectUSBdevices(USB1.0,USB1.1,USB2.0,andUSB
3.0compatible).
11Powerbutton
Thepowerbuttonisusedtoturnonorturnoffyournotebookcomputer,ortoputthenotebookcomputer
intosleeporhibernationmode.Toachievethis,youneedtochangethepowerplansettingsofyour
notebookcomputer.Formoreinformation,refertotheuserguidethatcomeswithyournotebookcomputer.
Chapter1.Aboutthedock3
