Lenovo ThinkPad OneLink Pro Dock User Manual

Locatingconnectorsandcontrolsonthedock
Thefollowingillustrationhelpsyoulocatetheconnectorsandcontrolsonthedock.
Figure1.Overviewofthedock
1Powerindicator8Powerconnector
2Headset/microphonecomboconnector9GigabitEthernetconnector
3USB3.0connectorwithbatterychargingfunction10USB3.0connectors
4USB3.0connector
11Powerbutton
5Security-lockslot12USB2.0connectors
6OneLinkcable
13DisplayPortconnector
7Cablemanagementstand
14DVI-Iconnector
1Powerindicator
Thepowerindicatorisusedtoindicatethepowerstatusofthenotebookcomputerthatconnectswiththe
dock.
•Ifthepowerindicatorislitinred,itindicatesthatthenotebookcomputeristurnedon.
•Ifthepowerindicatorisoff,itindicatesthatyournotebookcomputeristurnedoff,insleepmode,orin
hibernationmode;orthedockisdisconnectedfromyournotebookcomputer.
2Headset/microphonecomboconnector
Theheadset/microphonecomboconnectorisusedtoconnectaheadset,amicrophone,oraspeaker.
2ThinkPadOneLinkProDockUserGuide

Lenovo ThinkPad OneLink Pro Dock Specifications

General

Brand	Lenovo
Model	ThinkPad OneLink Pro Dock
Category	Docking Station
Language	English
