Lenovo ThinkPad USB-C Dock Gen 2 User Manual

Chapter 2. Set up the dock
Install the dock
Use the accompanying ac power adapter, power cord, and USB-C cable to install the dock. The dock
supplies power to the computer when the dock is connected to ac power and your computer.
HDMI
Install the dock driver
The dock driver is preinstalled on compatible computers and the dock is ready for use after you connect it to
ac power and computer.
You also can download the latest dock driver from the Lenovo Web site by doing the following:
1. Go to
https://www.lenovo.com/support/docks.
2. Select the entry for the dock and then follow the on-screen instructions.
© Copyright Lenovo 2019 5

Lenovo ThinkPad USB-C Dock Gen 2 Specifications

General

Certification	FCC/ICES, CE, KCC, RCM, BSMI, VCCI, CB, cULus, EAC, TUV- Mark, Serbia Kvalitet, LoA, Israel SII, Ukraine DoC, NOM
Compatibility	ThinkPad T490 (20N2, 20N3, 20Q9, 20QH), ThinkPad T590 (20N4, 20N5), ThinkPad X280 (20KE, 20KF), ThinkPad T480 (20L5, 20L6), ThinkPad X1 Carbon 6th (20KH, 20KG), ThinkPad X270 (20HM, 20HN, 20K5, 20K6), ThinkPad T480s (20L7, 20L8)
Product color	Black
Cable lock slot	Yes
Data transfer rate	10 Gbit/s
Brand compatibility	Lenovo
Card reader integrated	No
Maximum digital resolution	3840 x 2160 pixels
Number of displays supported	3
Headphone outputs	0
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	2
Connectivity technology	Wired
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
Power supply	90 W
AC input voltage	100 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Windows operating systems supported	Windows 10, Windows 7
Package depth	158 mm
Package width	210 mm
Package height	75 mm
Package weight	960 g
Quantity per pack	1 pc(s)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Cables included	AC, USB Type-C
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	20 - 95 %
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	80 mm
Width	171 mm
Height	30.75 mm
Weight	325 g
