1250AudioandcardreaderI/Ocard
Foraccess,removetheseFRUs,inorder:
“1010Batterypack”onpage68
“1040Harddiskdrive(HDD)cover,HDDandHDDrubberrailsorsolidstatedrive(SSD)andstorage
converter”onpage70
“1060Palmrestorpalmrestwithngerprintreader”onpage75
“1080Bluetoothdaughtercard(BDC-2.1)forW701andW701ds”onpage79
“1090Keyboard”onpage80
“1120DIMMslotcoverandDIMMunderkeyboardforW701andW701ds”onpage86
“1130Keyboardbezelandspeakerassembly”onpage88
“1140WirelessUSBadapterorIntelTurboMemoryMinicard”onpage93
“1150PCIExpressMiniCardforwirelessLAN/WiMAX”onpage94
“1220LCDunitandLCDcablecap”onpage113
“1230Structureframe”onpage118
Table45.RemovalstepsofaudioandcardreaderI/Ocard
1
StepScrew(quantity)Color
Torque
1
M2×3.5mm,wafer-head,nylon-coated(1)Silver
0.181Nm
(1.85kgfcm)
122ThinkPadW700,W700ds,W701,andW701dsHardwareMaintenanceManual
