For ThinkPad X13 Yoga Gen 4:

Table 16. Screw specification

Step Screw (quantity) Color Torque

M2.5 × 3.0 mm, flat-head, nylon-coated (6) Black 0.294 Nm

(3.0 kgf-cm)

2050 LCD panel, LCD cable and elastic adhesive tapes

For access, remove these FRUs in order:

• “1020 Base cover assembly” on page 69

• “2000 LCD unit” on page 95

• “2020 Strip cover (for ThinkPad X13 Yoga Gen 4 only)” on page 98

• “2030 LCD bezel sheet and LCD bezel (for ThinkPad X13 Gen 4 only)” on page 98

• “2040 LCD hinges” on page 99

Removal steps of LCD panel and elastic adhesive tapes

• ThinkPad X13 Gen 4

1. Pull out each tape slowly in the direction as shown until the adhesive tapes are all released from LCD

unit.

Note: Do not pull the tapes too fast, otherwise, the tapes might snap.

100

ThinkPad X13 Gen 4 and ThinkPad X13 Yoga Gen 4 Hardware Maintenance Manual
