Table32.Removalstepsofinvertercard(continued)
StepScrew(quantity)Color
Torque
1
M2×3.5mm,wafer-head,nylon-coated(2)Silver
0.181Nm
(1.85kgfcm)
Wheninstalling:Makesurethattheconnector3isattachedrmly.
2040Hinges
Foraccess,removetheseFRUsinorder:
•“1010Digitizerpen”onpage63
•“1020Batterypack”onpage63
•“1050Hingecaps”onpage69
•“1060Keyboard”onpage70
•“1070Extensioncablecard”onpage73
•“1080Palmrest”onpage74
•“1100PCIExpressMiniCardforwirelessLAN/WiMAX”onpage77
•“1110PCIExpressMiniCardforwirelessWAN”onpage80
•“1120IntelTurboMemoryMinicardorWirelessUSBPCIExpressHalf-MiniCard”onpage82
•“1140Keyboardbezel”onpage84
•“1170LCDassembly”onpage90
•“2010LCDfrontbezel”onpage104
•“2020Micro-Processorcard”onpage107
•“2030Invertercard”onpage109
110ThinkPadX200TabletandX201TabletHardwareMaintenanceManual
