Table33.Removalstepsofhinge
StepScrew(quantity)Color
Torque
1
M2.5×6mm,wafer-head,nylon-coated(2)
Black0.392Nm
(4kgfcm)
DetachthehingefromtheLCDrearcover,andgentlypullthecablesoutthroughtheguideholeinthehinge.Pull
themallatonce.Asyoupullthem,besurenottosubjectthemtoanytension,whichcouldcausethemtobe
damagedbythecableguides,orcouldbreakawire.
2050LCDpanel,LCDbracketLandR,andLCDcable
Foraccess,removetheseFRUsinorder:
•“1010Digitizerpen”onpage63
•“1020Batterypack”onpage63
•“1050Hingecaps”onpage69
•“1060Keyboard”onpage70
•“1070Extensioncablecard”onpage73
•“1080Palmrest”onpage74
•“1100PCIExpressMiniCardforwirelessLAN/WiMAX”onpage77
•“1110PCIExpressMiniCardforwirelessWAN”onpage80
•“1120IntelTurboMemoryMinicardorWirelessUSBPCIExpressHalf-MiniCard”onpage82
Chapter8.RemovingandreplacingaFRU111
