Table20.RemovalstepsofIntelTurboMemoryMinicardorWirelessUSBPCIExpressHalf-MiniCard(continued)
Wheninstalling:InmodelswiththeWirelessUSBPCIExpressHalf-MiniCard,plugtheyellowcableintothe
jackonthecard.
1130Bluetoothdaughtercard(BDC-2.1)
Foraccess,removetheseFRUsinorder:
•“1020Batterypack”onpage63
•“1060Keyboard”onpage70
•“1080Palmrest”onpage74
Table21.RemovalstepsofBluetoothdaughtercard
StepScrew(quantity)Color
Torque
1
M2×3.5mm,wafer-head,nylon-coated(1)Silver
0.181Nm
(1.85kgfcm)
Chapter8.RemovingandreplacingaFRU83
