Table19.RemovalstepsofPCIExpressMiniCardforwirelessWAN(continued)
StepScrew(quantity)Color
Torque
3
M2×3.5mm,wafer-head,nylon-coated(2)Silver
0.181Nm
(1.85kgfcm)
Wheninstalling:Whenyouinstallthecard,plugtheredcableintothejacklabeledMAINonthecard,andtheblue
cableintothejacklabeledAUX.
IfthecomputeryouareservicingisthewirelessWAN-readymodel,puttheantennacablesinthecableprotection
tubeandplacethemasshowninthisgure.
Chapter8.RemovingandreplacingaFRU81
