9.Notetheorientationofthenewbackplane.Carefullypressthenewbackplanestraightdownintothe
chassissothatitissecuredinplacebythetabs
1onthechassisandthethreescrewholesinthenew
backplanearealignedwiththecorrespondingholesinthechassis.Then,installthescrewstosecure
thenewbackplaneinplace.
Figure118.Installingthebackplaneforservermodelswith2.5-inchharddiskdrivebays
10.Reinstallallthehot-swapharddiskdrivesanddummytrays(ifany)intheharddiskdrivecage.See
“Installingorreplacingahot-swapharddiskdrive”onpage148
.
11.Refertoyournotetoconnectthecablestothenewbackplane.
12.Ifyouareinstructedtoreturntheoldhot-swapharddiskdrivebackplane,followallpackaging
instructionsanduseanypackagingmaterialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletethereplacement,goto“Completingthepartsreplacement”onpage182
.
Replacingtherisercardassembly1
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage81.
Thistopicprovidesinstructionsonhowtoreplacetherisercardassembly1.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Note:Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.
Toreplacetherisercardassembly1,dothefollowing:
Chapter6.Installing,removing,orreplacinghardware159
