3PCIExpresscardareaforcardsontherisercardassembly2
TherearethreePCIExpresscardslotsontherisercardassembly2forinstallingEthernetcardsorother
supportedPCIExpresscards.
Figure17.Risercardassembly2
Note:Theslot1andslot2aresupportedonlyinservermodelswithtwomicroprocessors.Forserver
modelswithonemicroprocessor,theslot1andslot2arecovered.Ifyouinstallthesecondmicroprocessor
intheserver,youneedtoremovethecoversthatprotecttheslot1andslot2beforeinstallingany
supportedcardsintotheslots.
PCIExpress
cardslot
Physicallink
width
Negotiablelinkwidth
Supportedcardlengthandheight
1
x16x8,x4,x2,x1
Half-length,full-heightcard
2
x8x8,x4,x2,x1
Half-length,full-heightcard
3
x8x4,x2,x1
Low-profilecard
28ThinkServerRD430HardwareMaintenanceManual
