Backplaneforservermodelswith123.5-inchharddiskdrivebays
Thistopicprovidesinformationtohelpyoulocatetheconnectorsonthebackplaneforservermodels
with123.5-inchharddiskdrivebays.
Thefollowingillustrationsshowtheconnectorsonthebackplaneforservermodelswith123.5-inchhard
diskdrivebays.
Figure30.Frontviewofthebackplaneforservermodelswith123.5-inchharddiskdrivebays
1Slot0fora3.5-inchharddiskdrive7Slot6fora3.5-inchharddiskdrive
2Slot1fora3.5-inchharddiskdrive8Slot7fora3.5-inchharddiskdrive
3Slot2fora3.5-inchharddiskdrive9Slot8fora3.5-inchharddiskdrive
4Slot3fora3.5-inchharddiskdrive10Slot9fora3.5-inchharddiskdrive
5Slot4fora3.5-inchharddiskdrive11Slot10fora3.5-inchharddiskdrive
6Slot5fora3.5-inchharddiskdrive12Slot11fora3.5-inchharddiskdrive
Figure31.Rearviewofthebackplaneforservermodelswith123.5-inchharddiskdrivebays
1Signalcableconnector5Signalcableconnector
2Mini-SASports8-11
68-pinpowerconnector
3Mini-SASports4-7
78-pinpowerconnector
4Mini-SASports0-3
1Signalcableconnector
UsedtoconnectthesignalcableforthefrontcontrolsandLEDsontherightrackhandle.
2Mini-SASports8-11
Usedtoconnectthemini-SASconnectorononeendofamini-SAStomini-SASsignalcabletosupportthe
harddiskdrive8toharddiskdrive11.
Chapter3.Productoverview41
