Table 7. Parts listing, Types 4203 (continued)
Index Description
CRU part
number
(Self-service)
CRU part
number
(Optional-
service)
FRU
part number
6 Hard disk drive, 750GB 7200 RPM 3.5-inch Hot-Swap
SATA II (models)
45J9646
6 Hard disk drive, 1TB 7200 SATA 3.5-inch Hot-Swap
(models)
45J9648
6 Hard disk drive, 146GB 10K 2.5-inch Hot-Swap SAS
(models)
45J9652
6 Hard disk drive, 73GB 10K 2.5-inch Hot-Swap SAS
(models)
45J9654
6 Hard disk drive, 146GB 15K 3.5-inch Hot-Swap SAS
(models)
45J9658
6 Hard disk drive, 300GB 15K 3.5-inch Hot-Swap SAS
(models)
45J9660
6 Hard disk drive, 500GB 7200 RPM 3.5″ Simple-Swap
SATA II (models)
46U1024
6 Hard disk drive, 450GB 15K SAS (all models) 46U2108
7 Adv Lenovo Bezel (all models) 46U2305
7 Entry & Mid Lenovo Bezel (all models) 46U2304
8 EMC Plates (all models) 41Y9125
9 SATA hard disk drive backplane (all models) 41Y9078
10 Fan Cage and Card (all models) 41Y9067
11 Fan (120 X 38mm) (all models) 41Y9028
12 Microprocessor duct (all models) 39Y8501
13 System board (models 11U 11G 11A) 44R5619
13 Tray, system board (all models) 41Y9077
14 Adaptec 8K adapter with Battery KEYBISCAYNE Raid
Card (all models)
25R8076
16 Easy LED Diagnostics panel assembly (all models) 41Y9079
17 SIDE COVER ASM (all models) 39Y8362
18 Blank Filler (all models) 39M6800
19 Heat sink (all models) 40K7438
20 Microprocessor, Intel Xeon 5110 Dual-Core 1.6 GHz/1066
MHz (2x 2 MB L2 cache) (models)
41Y4275
20 Microprocessor, Intel Xeon 5120 Dual-Core 1.86
GHz/1066 MHz (2x 2 MB L2 cache) (models)
41Y4276
20 Microprocessor, Intel Xeon 5130 Dual-Core 2.0 GHz/1333
MHz (2x 2 MB L2 cache) (models)
41Y4277
20 Microprocessor, Intel Xeon 5140 Dual-Core 2.33
GHz/1333 MHz (2x 2 MB L2 cache) (models)
41Y4278
20 Microprocessor, Intel Xeon 5150 Dual-Core 2.66
GHz/1333 MHz (2x 2 MB L2 cache) (models)
41Y4279
20 Microprocessor, Intel Xeon 5160 Dual-Core 3.0 GHz/1333
MHz (2x 2 MB L2 cache) (models)
41Y4280
52 ThinkServer TD100 and TD100x: Hardware Maintenance Manual
|
|
|
|
