Lenovo ThinkServer RS140 Product Guide

System specifications
The following table lists the system specifications.
Table 1. System specifications
Components Specification
Form factor 1U rack-mount
Processor One Intel Xeon processor E3-1200 v3 product family with four cores up to 3.7 GHz, 8
MB cache, and up to 1600 MHz memory speed; or
One Intel Core-i3 Processor 4100/4300 product families with two cores up to 3.7 GHz,
up to 4 MB cache, and 1600 MHz memory speed; or
One Intel Pentium Processor G3200/G3400 product families with two cores up to 3.4
GHz, 3 MB cache, and up to 1600 MHz memory speed; or
One Intel Celeron Processor G1800 product family with two cores up to 2.9 GHz, 2 MB
cache, and up to 1333 MHz memory speed.
Chipset Intel C226.
Memory Four DIMM sockets. Support for UDIMMs. DIMM speeds up to 1600 MHz.
Memory
maximums
Up to 32 GB with four 8 GB UDIMMs.
Memory protection Error-correcting code (ECC) memory
Drive bays Four 2.5-inch non-hot-swap SAS/SATA drive bays; or
Two 3.5-inch SAS/SATA non-hot-swap drive bays.
Drive types 2.5-inch drives:
SAS HDDs
Nearline (NL) SATA HDDs
SATA SSDs
3.5-inch drives
NL SAS HDDs
NL SATA HDDs
Intermix of SAS and SATA HDDs and SSDs is supported within a system, but not within a
RAID array.
Maximum internal
storage
Up to 3.6 TB with 900 GB 2.5-inch SAS HDDs; up to 4 TB with 1 TB 2.5-inch NL SAS/SATA
HDDs; up to 2.4 TB with 600 GB 2.5-inch SATA SSDs; or up to 12 TB with 6 TB 3.5-inch NL
SATA HDDs.
RAID support Non-RAID with the integrated SATA controller or PMC8885e.
RAID 0, 1, 10, and 5 with ThinkServer RAID 100.
RAID 0, 1, and 10 with ThinkServer RAID 500; optional RAID 5 upgrade is available for
Lenovo RAID 500.
RAID 0, 1, 10, 5, and 6 with ThinkServer RAID 700.
Optical drive bays One. Support for DVD-ROM or DVD-RW.
Tape drive bays None.
Network interfaces Three integrated Gigabit Ethernet (10/100/1000 Mbps) RJ-45 ports:
One onboard shared port for management and data (Intel i217LM)
Two ports on a LAN card (Intel i210AT) installed in a server
I/O expansion slots One PCIe 3.0 x8 (x8-wired); full-height, half-length.
Ports Front: Two USB 2.0 ports.
Rear: Four USB 3.0 ports, two USB 2.0 ports, one DisplayPort, one DB-15 video port,
one DB-9 serial port, three RJ-45 GbE network ports.
Lenovo ThinkServer RS140 5
