Error code
POST error message
Description/Action
0164 Memory configuration change has
occurred
This error message is displayed
when the memory size is
changed.
Press F10 to exit.
1762
Storage device configuration change
has occurred
This error message is displayed
when a hard disk drive change or
an optical drive change has been
made.
Press F10 to exit.
8998 Not enough shadow RAM resources
for OPTION ROM, not all devices
initialized. Suggest to remove some
add-on cards, or change to UEFI
mode in BIOS setup.
This error message is displayed
when the shadow RAM resources
for option ROM are insufficient.
If the legacy option ROM is
insufficient, remove some add-in
cards.
For the system that supports
UEFI, set UEFI as the first priority.
8999
Not enough PCIe/PCI MMIO
resources. Currently only one video
card is enabled. Remove some PCIe
cards.
This error message is displayed
when the PCIe/PCI MMIO
(memory mapped input/output)
resources are insufficient.
Remove some add-in cards.
Miscellaneous error conditions
Message/Symptom
FRU/Action
Changing display colors Display/Monitor
Hub will not power-off.
1. Power Switch
2. System Board
Hub will not RPL from server
1. Ensure that the network is in startup sequence as the
first device or the first device after diskette.
2. Ensure that the network adapter is enabled for RPL.
3. Network adapter (Advise network administrator of
new MAC address)
Hub will not perform a Wake On LAN
®
(if applicable)
1. Check the power supply and signal cable
connections to the network adapter.
2. Ensure that the operating system settings are set to
enable Wake on LAN.
3. Ensure that the Wake On LAN feature is enabled in
Setup/Configuration.
4. Ensure that the network administrator is using the
correct MAC address.
5. Ensure no interrupt or I/O address conflicts.
6. Network adapter (advise network administrator of
new MAC address)
34 ThinkSmart Hub Hardware Maintenance Manual
