Lenovo ThinkStation C20x Hardware Maintenance Manual

Figure3.Componentlocations
1Microprocessor19Harddiskdrivebay
2Memorymodules
10Harddiskdrives(3)
3Heatsinkandfanassembly2
11Systemboard
4Microprocessor212Powersupplyassembly
5Opticaldrivebracket13PCIcard
6Opticaldrive
14Heatsinkandfanassembly1
7InternalSpeaker15Rearfanassemblies(2)
8Frontfanassemblybracket
Locatingpartsandconnectorsonthesystemboard
Note:Yourcomputercomeswithoneofthefollowingsystemboards.
Figure4“Systemboardpartandconnectorlocations”onpage72
showsthelocationsofthepartsand
connectorsononetypeofsystemboard.
Chapter9.ReplacingFRUs71
