Figure17.InstallinganewPCIcard
7.ReinstallthePCIcardholderintothechassis.See“RemovingandreinstallingthePCIcardholder”
onpage76.
8.Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage110.
Installinganewharddiskdrive
Attention
Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafety
information”intheThinkStationSafetyandWarrantyGuidethatcamewithyourcomputer.Toobtainacopy
oftheThinkStationSafetyandWarrantyGuide,goto:
http://www.lenovo.com/support
Thissectionprovidesinstructionsonhowtoinstallanewharddiskdriveintoyourcomputer.
Toinstallanewharddiskdrive,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandthecomputer.Then,disconnect
allpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtothecomputer.
2.Removethecomputercover.See“Removingthecomputercover”onpage74.
3.Removethefrontbezel.See“Removingandreinstallingthefrontbezel”onpage75.
4.RemovethePCIcardholder.See“RemovingandreinstallingthePCIcardholder”onpage76.
5.Pullthehandleofaspareharddiskdrivebracketouttoremovethebracketfromtheharddiskdrivebay.
6.Toinstallanewharddiskdriveintothebracket,exthesidesofthebracketproperlyandalignpin1,
pin
2,pin3,andpin4onthebracketwiththecorrespondingholesintheharddiskdrive.Donot
touchthecircuitboard5ontheharddiskdrive.
84ThinkStationHardwareMaintenanceManual
