Management
ports
One 10/100/1000 Mb Ethernet port (UTP, RJ-45); one RS-232 port (RJ-45); one USB port (for
additional firmware/log/configuration files storage).
Management
interfaces
EZSwitch Setup; Web-based GUI (Web Tools); Command Line Interface (CLI); SMI-S; SNMP;
REST API. Optional Brocade Network Advisor.
Security features Secure Socket Layer (SSL); Secure Shell (SSH); Secure Copy (SCP); Secure FTP (SFTP); user
level security, Role-based Access Control (RBAC); LDAP, RADIUS, and TACACS+
authentication; access control lists (ACLs); IP security (IPsec)
Hardware
warranty
One-year customer-replaceable unit limited warranty with 9x5 next business day parts
delivered. Optional warranty service upgrades are available through Lenovo: on-site coverage
(technician installed parts), 24x7 coverage, 2-hour or 4-hour response time, 6-hour or 24-hour
committed repair, up to 5 years of warranty coverage, 1-year or 2-year warranty extensions,
Remote Technical Support, hardware installation services.
Software
maintenance
Three-year software support and subscription license is included. Optional 1-year and 2-
year software support extension licenses are available through Lenovo.
Dimensions Height: 43 mm (1.7 in.); width: 429 mm (16.9 in.); depth: 307 mm (12.1 in.)
Weight Empty: 4.2 kg (9.3 lb); Fully configured: 5.8 kg (12.7 lb).
Component Specification
Models
The following table lists the ThinkSystem DB610S FC SAN Switch models.
Table 2. Lenovo ThinkSystem DB610S FC SAN Switch models
Description
Part
number
Machine
Type-Model
Feature
code
Lenovo ThinkSystem DB610S, 24 ports activated, 24x 16Gb SWL SFPs,
1 PS, Rail Kit, Enterprise SW
6559D1Y 6559-HC1 AVPQ
Lenovo ThinkSystem DB610S, 8 ports activated, 8x 16Gb SWL SFPs,
1 PS, Rail Kit
6559D2Y 6559-HC2 AVPR
Lenovo ThinkSystem DB610S, 8 ports activated, 1 PS, Rail Kit 6559D3Y 6559-HC3 AVPS
The DB610S FC SAN Switch part numbers include the following items:
One FC SAN Switch
Model HC1: With 24 ports activated and 24x 16 Gb FC SWL SFP+ transceivers included
Model HC2: With 8 ports activated and 8x 16 Gb FC SWL SFP+ transceivers included
Model HC3: With 8 ports activated and no transceivers included
Serial cable (DB-9/RJ-45 to RJ-45)
Fixed rack mount kit
EZSwitch Setup web pointer card
Online Documentation web pointer card
Network Advisor web pointer card
Note: The switch comes standard without a power cord; one power cable must be purchased together
with the switch (see Power supplies and cables for details).
Port activation licenses
Lenovo ThinkSystem DB610S 32Gb FC SAN Switch 4
