The following table lists the cabling requirements for the switch.
Table 5. DB610S FC SAN Switch cabling requirements
Transceiver Standard Cable Connector
32 Gb Fibre Channel
32 Gb FC SWL SFP+
(01KN789, 01KN793)
FC-PI-6 Up to 30 m with fiber optic cables supplied by Lenovo (see
Table 4).
850 nm 50 µ multi-mode fiber optic cable:
32GFC: Up to 100 m (OM4) or up to 70 m (OM3)
16GFC: Up to 125 m (OM4) or up to 100 m (OM3)
8GFC: Up to 190 m (OM4) or up to 150 m (OM3)
LC
32 Gb FC LWL SFP+
(01KN795, 01KN799)
FC-PI-6 1310 nm 9 µ single-mode fiber optic cable:
32GFC, 16GFC, 8GFC: Up to 10 km
LC
16 Gb Fibre Channel
16 Gb FC SWL SFP+
(88Y6393)
FC-PI-5 Up to 30 m with fiber optic cables supplied by Lenovo (see
Table 4).
850 nm 50 µ multi-mode fiber optic cable:
16GFC: Up to 125 m (OM4) or up to 100 m (OM3)
8GFC: Up to 190 m (OM4) or up to 150 m (OM3)
4GFC: Up to 400 m (OM4) or up to 380 m (OM3)
LC
16 Gb FC LWL SFP+
(00MY768)
FC-PI-5 1310 nm 9 µ single-mode fiber optic cable:
16GFC, 8GFC: Up to 10 km
4GFC: Up to 30 km
LC
16 Gb FC ELWL
SFP+ (00MY770)
FC-PI-5 1310 nm 9 µ single-mode fiber optic cable:
16GFC: Up to 25 km
LC
Management ports
10/100/1000 Mb
Ethernet port
1000BASE-T Up to 25 m with UTP cables supplied by Lenovo (see Table 4).
UTP Category 5, 5E, and 6 up to 100 meters
RJ-45
Serial port RS-232 DB-9/RJ-45-to-RJ-45 console cable (comes with the switch) RJ-45
