Server top view (2.5-inch drive model)
Figure 7. Server top view (2.5-inch drive model)
1 Power supply bays 7 Fans
2 PCIe riser
8 Intrusion switch
3 System board
9 Drive backplane
4 Processor
10 CFF RAID adapter
5 Memory module slots 11 Flash power module
6 Air baffle
12 Power distribution board cover
Chapter 2. Server components 23
