The following figure shows the locations of key components inside the SR590 server.
Figure 6. Internal view of the SR590
System specifications
The following table lists the system specifications for the SR590 server.
Table 1. SR590 system specifications
Attribute Specification
Form factor 2U rack-mount.
Processor Up to two Intel Xeon Bronze, Silver, Gold, or Platinum processors of up to 150 W TDP:
Up to 26 cores (2.0 GHz core speeds)
Up to 3.6 GHz core speeds (4 cores)
Two UPI links up to 10.4 GT/s each
Up to 35.75 MB cache
Up to 2666 MHz memory speed
Chipset Intel C622.
Memory Up to 16 DIMM sockets (8 DIMMs per processor; 6 memory channels per processor with
one DIMM per channel for four channels and two DIMMs per channel for two channels). Support
for RDIMMs or LRDIMMs. Memory types cannot be intermixed. Memory speed up to 2666 MHz.
