Figure 5. Server top view
Table 11. Component identification (top view)
1 Front backplane(s)
2 Intrusion switch
3 System fans
4 Memory modules
5 Processors and heat sinks 6 Riser assemblies
7 System board assembly
Note: The illustration shows the server rear configuration with three riser assemblies. The server rear
configurations vary by server model. For details, see
“Rear view” on page 17.
System-board-assembly layout
This section provides information about the connectors, switches, and jumpers that are available on the
system board assembly.
The following illustration shows the layout of the system board assembly that contains the firmware and RoT
security module, system I/O board, and processor board.
20
ThinkSystem SR665 V3 System Configuration Guide
