Lenovo ThinkSystem SR665 V3 - System-Board-Assembly Connectors

Figure 6. System-board-assembly layout
1 System I/O board
2 Firmware and RoT security module 3 Processor board
For information about the LEDs that are available on the system board assembly, see:
•
“System-board-assembly LEDs” on page 36
• “LEDs on the firmware and RoT security module” on page 38
• “System-board-assembly connectors” on page 21
• “System-board-assembly switch” on page 23
System-board-assembly connectors
This section provides information about the internal connectors on the system I/O board and processor
board.
Chapter 2. Server components 21
