1 PCIe riser 1 (PCIe slot 3-5)
Install PCIe adapters into these slots. See the following table for PCIe slots corresponding to the PCIe risers.
PCIe slot
x8/x16/x16 PCIe G4
Riser 1/3 FHFL
7mm/x16 PCIe G4
Riser 1 FHHL
x16/x16 PCIe G5
Riser 1/3 FHFL
7mm/x16 PCIe G5
Riser 1 FHHL
3
x16 (Gen4 x8)
7mm drive cage
N/A
7mm drive cage
4
x16 (Gen4 x16)
* x16 (Gen5 x16) *
5
x16 (Gen4 x16) x16 (Gen4 x16) x16 (Gen5 x16) x16 (Gen5 x16)
Note: * Slot 4 supports a double-wide, FHFL GPU installed in slot 3 and 4.
2 PCIe riser 2 (PCIe slot 6-8)
Install PCIe adapters into these slots. See the following table for PCIe slots corresponding to the PCIe risers.
PCIe slot
x16/x8/x8 PCIe G4
Riser 2/A/B/C HHHL
x16/x8/Serial PCIe
G4 Riser 2/C HHHL
x16/x8/x8 PCIe G5
Riser 2/A/B/C HHHL
x16/x8/Serial PCIe
G5 Riser 2/C HHHL
6
x16 (Gen4 x16) x16 (Gen4 x16) x16 (Gen5 x16) x16 (Gen5 x16)
7
x16 (Gen4 x8) x16 (Gen4 x8) x16 (Gen5 x8) x16 (Gen5 x8)
8
x16 (Gen4 x8) Serial port bay x16 (Gen4 x8) Serial port bay
3 PCIe riser 3 (PCIe slot 9-11)
Install PCIe adapters into these slots. See the following table for PCIe slots corresponding to the PCIe risers.
PCIe slot x8/x16/x16 PCIe G4 Riser 1/3 FHFL x16/x16 PCIe G5 Riser 1/3 FHFL
9
x16 (Gen4 x8)
N/A
10
x16 (Gen4 x16) * x16 (Gen5 x16) *
11
x16 (Gen4 x16) x16 (Gen5 x16)
Note: * Slot 10 supports a double-wide, FHFL GPU installed in slot 9 and 10.
4 Power supply units
Install power supply units to these bays, connect them to power cords. Make sure the power cords are
connected properly. Following are the power supplies supported by this system:
• CFFv4
– 1100-watt Platinum, input power 115 Vac / 230 Vdc / 240 Vdc
– 1100-watt Titanium, input power 115 Vac / 230 Vdc/ 240 Vdc
– 1800-watt Platinum, input power 230 Vac / 240 Vdc
– 1800-watt Titanium, input power 230 Vac / 240 Vdc
– 2400-watt Platinum, input power 230 Vac / 240 Vdc
– 2600-watt Titanium, input power 230 Vac / 240 Vdc
• CRPS (Chinese Mainland Only)
– 1300-watt Platinum, input power 115 Vac / 230 Vac / 240 Vdc
– 2700-watt Platinum, input power 230 Vac / 240 Vdc
Chapter 2. Server components 21
