Lenovo ThinkSystem SR850 V3 - Top View of the Sever Model with Four Pcie; Risers

Figure 13. Top view of the sever model with three PCIe risers
Table 5. Components on the top view of the sever model with three PCIe risers
1 Drive backplanes
6 Intrusion switch
2 Fan cage and fans 7 Power backplane
3 System board assembly
8 Power supply bays
4 Memory modules
9 PCIe risers
5 Processors
Note: The illustration shows the location of certain parts. Some parts may not be supported at the same
time within certain configuration(s).
Top view of the sever model with four PCIe risers
This section contains information on the top view of the sever model with four PCIe risers.
