Table 2-2. OSD functions
OSD Icon on Main Menu Submenu Description
Controls and
Adjustments
Brightness/Contrast
Brightness Adjusts overall brightness
Brightness/Contrast
Contrast
Adjusts difference between
light and dark areas.
Brightness/Contrast
DCR
Enable dynamic contrast ratio.
On
Off
Image Position
Horizontal Position
Moves the image left or
right.
Image Position
Vertical Position
Moves the image up or Down.
Image Setup
Automatic
Automatically optimizes the
image.
Image Setup
Manual
Manually optimizes the image.
See “Manual image setup” on
page 3-3
● Clock
● Phase
Image Properties
Input Signal
Analog
DISPLAYPORT
Select Analog Signal
Select DP Signal
Image Properties
Color
Adjusts intensity of red, green,
and blue.
Preset mode
● Neutral
● sRGB
● Reddish
● Bluish
Custom
● Red: Increases or decreases
the saturation of ‘red’ in the
image.
● Green: Increases or
decreases the saturation of
‘green’ in the image.
● Blue: Increases or
decreases the saturation of
‘blue’ in the image.
● Save: Saves the custom
colour choices.
Image Properties
Scaling
● Full Screen
● Original AR
Image Properties
Low Blue Light
Enable Low Blue Light
● On
●
Off
Image Properties
Over Drive
Response time enhancement
● Normal
● Extreme
● Off
2-5 E24-10 Flat Panel Monitor User’s Guide
