Lenovo V510z User Manual

Replacing FRUs 44
Replacing the Wi-Fi card
Attention
Do not open your computer or attempt any repairs before reading the Important
Product Information Guide.
1
Remove the computer stand. For details, see Replacing the monitor stand or Replacing the UltraFlex II
Stand.
2
Remove the computer cover. For details, see Removing the computer cover.
3
Remove the optical drive. For details, see Replacing the optical drive.
4
Remove the VESA mount bracket. For details, see Replacing the VESA mount bracket.
5
Remove the middle frame. For details, see Replacing the middle frame.
6
Remove the system board shield. For details, see Replacing the system board shield.
7
Replace the Wi-Fi card.
1 2
3 4

Lenovo V510z Specifications

General

Operating System	Windows 10 Pro
Display	1920 x 1080
RAM	DDR4
Storage	1TB HDD
Graphics	Intel HD Graphics
Ports	USB 3.0, USB 2.0, HDMI, Audio jacks
Optical Drive	DVD-RW
Webcam	720p
Audio	Stereo speakers
Wireless	Wi-Fi 802.11ac, Bluetooth 4.0
Weight	6 kg
