Information LH100 V3 7
DIGITAL plus
3 First steps
In this section you will find out how:
- to connect your LH100 to a LZ100 or a SET02 command
station.
- to operate your first train
The following sections below will then explain all the functions of
LH100 in detail.
3.1 Connections and starting operation
The LH100 can be connected to any XpressNET system including
the following components of the Digital plus by Lenz
®
system:
LZ100; SET02; SET03; Compact
It may also be used with other XpressNET systems including the
Atlas Commander and the Roco Lokmaus 2 system.
FF As with all XpressNET devices, you can disconnect your
LH100 during operation and reconnect it later when you
wish. To make the maximum use of this advantage of
XpressNET, install several connector plates LA152/LA153
or install 5 pin din plugs around your layout. You will then
always be able to use the LH100 right at the desired place
of action.
3.1.1 Connecting to command station LZ100
Insert the 5-pin DIN-connector
- in the 5-pin DIN-jack on the back of your LZ100
or, if you have already installed XpressNET (XBUS) wiring on
your layout
- to a connector plate LA150, LA152, or 5 pin DIN plug
3.1.2 Connecting to SET02 or Atlas Commander
Insert the 5-pin DIN-connector into a LA152/153 connection plate
that is connected to SET02 or Commander or to an installed 5 pin
DIN plug.
3.1.3 Setting the XpressNET - Address
All input devices connected to XpressNET (XBUS) must have
their own unique device address for the information exchange to
function correctly. You must therefore make sure that each
connected device has its own unique address. Up to 31 devices
can be connected to XpressNET, ie. you can program each
device
