46 SF01U
04 RESET 60: Resets the user parameters to the factory defaults for a 60 Hz base
frequency.
05 RESET 50: Resets the user parameters to the factory defaults for a 50 Hz base frequency.
Parameters 24, 27, and 40 will reset to 50.0 Hz.
06 TRANSLATE: If an EPM from a drive with a previous parameter version is installed
in a new drive, the new drive will function like the previous version drive, but none of
the parameter settings can be changed ("cE" will be displayed if this is attempted).
The TRANSLATE function converts the EPM to the new parameter version so that the
parameters can be changed, but it also retains the old parameter settings so the new
drive will operate like the old drive without having to re-program all of the parameters.
NOTE
• If the user parameters are reset to the OEM defaults (using the RESET
OEM option), and then OPERATE WITH USER SETTINGS is selected,
the USER settings will be the same as the OEM default settings. This
allows the drive to operate as if it was in OEM mode, but the parameter
values can be changed. This is useful if some of the OEM default settings
need to be fine-tuned for proper operation. The new parameter values are
not actually stored as new OEM default settings however; they are simply
stored as new USER settings. Therefore, if the parameters are reset to
the OEM defaults again, the parameters that were changed will be reset
to their “old” value. The optional EPM Programmer is required to change
OEM default settings. Refer to Section 13.2.
• Only the TRANSLATE (06) function can be performed while the drive is
running. The display will flash "Er" if an attempt is made to select any
other function while the drive is running.
P50 FAULT HISTORY
The FAULT HISTORY stores the last eight faults that tripped the drive. Refer to Section 16.0
- TROUBLESHOOTING for a list of the faults and possible causes.
Use the and buttons to scroll through the fault entries. The far left digit of the display will
be the fault number and the remaining two digits will be the fault code. The faults are stored
from newest to oldest, with the first fault shown being the most recent.
The display will read “_ _” if the FAULT HISTORY does not contain any fault messages.
P51 SOFTWARE VERSION
This displays the software version number for the control board software. This information is
useful when contacting the factory for programming or troubleshooting assistance.
The software version is displayed in two parts which alternate. The first part is the software
version, and the second part is the revision number. For example, if the display shows "64-"
and "-02", this indicates that the drive contains the second revision of version 64 software.
P52 DC BUS VOLTAGE
This displays the DC bus voltage in percent of nominal. Nominal DC bus voltage is determined
by multiplying the drive’s nameplate input voltage rating by 1.4.
P53 MOTOR VOLTAGE
This displays the output voltage in percent of the drive’s nameplate output voltage rating.
