30 SF01U
14.0 PARAMETER MENU
NOTE: If the drive is equipped with the PI option, please refer to Appendix B for additional
parameter information.
NOTE 1: Factory defaults are shown for a 60 Hz base frequency. See Parameter 48 for 50 Hz base frequency.
NO. PARAMETER NAME RANGE OF ADJUSTMENT
FACTORY
DEFAULT
(NOTE 1)
01 LINE VOLTAGE HIGH (01), LOW (02) HIGH (01)
02 CARRIER FREQUENCY 4kHz (01), 6 kHz (02), 8 kHz (03), 10 kHz (04) 6 kHz (02)
03 START METHOD
NORMAL (01), START ON POWER UP (02),
START WITH DC BRAKE (03),
AUTO RESTART WITH DC BRAKE (04),
FLYING RESTART 1 (05),
FLYING RESTART 2 (06),
FLYING RESTART 3 (07)
NORMAL (01)
04 STOP METHOD
COAST (01), COAST WITH DC BRAKE (02),
RAMP (03), RAMP WITH DC BRAKE (04)
COAST (01)
05
STANDARD
SPEED SOURCE
KEYPAD (01), PRESET #1 (02),
0-10 VDC (03), 4-20 mA (04)
KEYPAD (01)
06
13
TB-14 OUTPUT
TB-15 OUTPUT
NONE (01), RUN (02), FAULT (03),
INVERSE FAULT (04), FAULT LOCKOUT (05),
AT SET SPEED (06), ABOVE PRESET #3 (07),
CURRENT LIMIT (08), AUTO SPEED (09),
REVERSE (10)
NONE (01)
08 TB-30 OUTPUT
NONE (01), 0-10 VDC FREQ (02),
2-10 VDC FREQ (03), 0-10 VDC LOAD (04),
2-10 VDC LOAD (05)
NONE (01)
09 TB-31 OUTPUT
NONE (01), 0-10 VDC LOAD (02)
2-10 VDC LOAD (03), DYNAMIC BRAKING (04)
NONE (01)
10
TB-13A FUNCTION
SELECT
NONE (01), 0-10 VDC (02), 4-20 mA (03),
PRESET SPEED #1 (04),RUN REVERSE (05),
START REVERSE (06), EXTERNAL FAULT (07),
REMOTE KEYPAD (08), DB FAULT (09),
AUXILIARY STOP (10), ACCEL/DECEL #2 (11)
NONE (01)
11
TB-13B FUNCTION
SELECT
NONE (01), 0-10 VDC (02), 4-20 mA (03),
PRESET SPEED #2 (04), DECREASE FREQ (05),
JOG FORWARD (06), JOG REVERSE (07)
AUXILARY STOP (08)
NONE (01)
