SF01U 7
NOTE: Refer to Appendix A for mounting template dimensions for the Through-hole Mount option.
HP kW
INPUT
VOLTAGE
MODEL H W D P
10 7.5
208 / 240 SF2100F 15.59 (396) 11.14 (283) 7.65 (194) 3.60 (91)
400 / 480 SF4100F 11.59 (294) 11.14 (283) 7.65 (194) 3.60 (91)
480 / 590 SF5100F 11.59 (294) 11.14 (283) 7.65 (194) 3.60 (91)
15 11
208 / 240 SF2150F 18.09 (459) 11.14 (283) 8.29 (211) 3.60 (91)
400 / 480 SF4150F 15.59 (396) 11.14 (283) 8.29 (211) 3.60 (91)
480 / 590 SF5150F 15.59 (396) 11.14 (283) 8.29 (211) 3.60 (91)
20 15
400 / 480 SF4200F 18.09 (459) 11.14 (283) 8.29 (211) 3.60 (91)
480 / 590 SF5200F 18.09 (459) 11.14 (283) 8.29 (211) 3.60 (91)
25 18.5
400 / 480 SF4250F 28.50 (724) 10.34 (263) 8.39 (213) 3.70 (94)
480 / 590 SF5250F 28.50 (724) 10.34 (263) 8.39 (213) 3.70 (94)
3.0 SCF MODEL DESIGNATION CODE
The SCF model number gives a full description of the basic drive unit (see example below).
EXAMPLE: SF210Y (SCF Series, 208/240 Vac, 1 HP, single or three phase input)
SF 2 10 Y
Series:
SF = SCF Series Variable Speed AC Motor Drive
Input Voltage:
2 = 208/240 Vac (For 208, 230, and 240 Vac; 50 or 60 Hz)
4 = 400/480 Vac (For 380, 415, 440, 460 and 480 Vac; 50 or 60 Hz)
5 = 480/590 Vac (For 440, 460, 480, 575 and 600 Vac; 50 or 60 Hz)
Rating:
03 = ¼ HP (0.20 kW) 30 = 3 HP (2.2 kW) 200 = 20 HP (15 kW)
05 = ½ HP (0.37 kW) 50 = 5 HP (4.0 kW) 250 = 25 HP (18.5 kW)
10 = 1 HP (0.75 kW) 75 = 7½ HP (5.5 kW) 300 = 30 HP (22 kW)
15 = 1½ HP (1.1 kW) 100 = 10 HP (7.5 kW)
20 = 2 HP (1.5 kW) 150 = 15 HP (11 kW)
Input Phase:
Y = Single or three phase input.
No character indicates three phase input only
Mounting Style:
F = Through-hole mount with special heatsink
F1 = Through-hole mount without heatsink (customer supplies heatsink)
No character indicates panel or DIN rail mounting
Application Specific Options:
P = PI (setpoint control) software
V = High Frequency Output - up to 1000 Hz
