SF01U 9
5.0 SCF RATINGS
MODEL
NUMBER
(NOTE 1)
FOR MOTORS
RATED
INPUT (50-60 Hz) OUTPUT HEAT LOSS
(WATTS)
(NOTE 5)
INPUT
PHASE
CURRENT
(AMPS)
POWER
(kVA)
CURRENT
(AMPS)HP kW
SF200Y SERIES (NOTE 2) 208 / 240 Vac 0 - 200 / 230 Vac STD THRU
SF203Y 0.25 0.20 1 3.6 / 3.2 0.76 1.6 / 1.4 19 N/A
SF203Y 0.25 0.20 3 1.9 / 1.7 0.71 1.6 / 1.4 19 N/A
SF205Y 0.5 0.37 1 5.4 / 4.7 1.2 2.5 / 2.2 26 N/A
SF205Y 0.5 0.37 3 3.1 / 2.7 1.1 2.5 / 2.2 26 N/A
SF210Y 1 0.75 1 10.6 / 9.2 2.2 4.8 / 4.2 49 18
SF210Y 1 0.75 3 5.8 / 5.1 2.1 4.8 / 4.2 49 18
SF215Y 1.5 1.1 1 13.9 / 12.0 2.9 6.9 / 6.0 82 23
SF215Y 1.5 1.1 3 8.0 / 6.9 2.9 6.9 / 6.0 82 23
SF220Y 2 1.5 1 14.8 / 12.9 3.1 7.8 / 6.8 86 26
SF220Y 2 1.5 3 9.1 / 7.9 3.2 7.8 / 6.8 86 26
SF230Y 3 2.2 1 19.7 / 17.1 4.1 11.0 / 9.6 130 29
SF230Y 3 2.2 3 12.4 / 10.8 4.4 11.0 / 9.6 130 29
SF250Y 5 3.7 1 29 / 26 6.1 17.5 / 15.2 212 40
SF250Y 5 3.7 3 19.6 / 17.1 7.1 17.5 / 15.2 212 40
SF200 SERIES (NOTE 2) 208 / 240 Vac 0 - 200 / 230 Vac
SF210 1 0.75 3 5.8 / 5.1 2.1 4.8 / 4.2 41 11
SF215 1.5 1.1 3 8.0 / 6.9 2.9 6.9 / 6.0 69 13
SF220 2 1.5 3 9.1 / 7.9 3.3 7.8 / 6.8 78 15
SF230 3 2.2 3 12.4 / 10.8 4.5 11.0 / 9.6 117 20
SF250 5 3.7 3 19.6 / 17.1 7.1 17.5 / 15.2 187 22
SF275 7.5 5.5 3 28 / 25 10.3 25 / 22 286 31
SF2100 10 7.5 3 34 / 32 13.1 30 / 28 379 39
SF2150 15 11 3 54 / 48 20.0 48 / 42 476 51
SF2200 20 15 3 65 / 61 25.4 58 / 54 648 N/A
NOTE 1: See Section 3.0 for model number breakdown.
NOTE 2: The higher current ratings are for 208 Vac input and the lower current ratings are for 240 Vac input.
NOTE 5: STD = standard unit; THRU = through-hole mount unit. Values are worst-case (not typical) for 6kHz carrier
frequency at full speed and full load.
