Technical data
General data and operating conditions
3
35
EDK84DGDVBxxx4 DE/EN/FR/ES/IT 3.1
Protection of persons and equipment
Short−circuit strength EN 61800−5−1
Connection:
Motor To a limited extent, the
controller is inhibited, error
acknowledgement required
Motor holding brake,
brake resistor
No
PTC, control terminals Full
Earth−fault strength EN 61800−5−1
Connection:
Motor (at controller
enable)
To a limited extent, the
controller is inhibited, error
acknowledgement required
Motor (during
operation)
No
Brake resistor, PTC No
Starting current £ 2 x I
N
Supply conditions
Mains connection
Power system
TT, TN
(with earthed
neutral)
Operation is permitted without any restrictions.
IT Apply the measures described for IT systems (remove
IT screw).
Motor connection
Motors EN 60034 Only use motors suitable for inverter operation.
Insulation resistance:
min. û ³ 1.5 kV, min. du/dt ³5 kV/ms
Length of the motor
cable
< 20 m (Lenze system cable, shielded)
