ENGLISH
16
Commissioning
Code Possible Settings
IMPORTANT
No. Name Lenze Selection
1
Auto-TRIP reset delay 0.0 0.0 {s} 60.0 See c70
Operating time
counter
Display
Total time in status “Start”
0...999 h: format xxx
1000...9999 h: format x.xx (x1000)
10000...99999 h: format xx.x (x1000)
Mains connection
time counter
Display
Total time of mains = on
1
PI setpoint 0.0 c86 c87
2
S-ramp integration
time
0.0 0.0 {s} 50.0 • c82 = 0.0: Linear accel/decel ramp
• c82 > 0.0: Adjusts S-ramp curve for
smoother ramp
Minimum feedback 0.0 0.0 999 • Select feedback signal at C34
• If feedback is reverse-acting, set
c86>c87
7
Maximum feedback 100 0.0 999
PI setpoint accel/
decel
5.0 0.0 {s} 999 Sets rate of change for PI setpoint
PI mode 0 0 PI disabled
1 PI enabled: normal-acting When feedback (terminal 8) exceeds
setpoint, speed decreases
2 PI enabled: reverse-acting When feedback (terminal 8) exceeds
setpoint, speed increases
Feedback minimum
alarm
0.0 0.0 999
See C08, selections 9 and 10
7
Feedback maximum
alarm
0.0 0.0 999
