Configuration
821XKlimaBA0399 7-5
Code IMPORTANTPossible settingsNameCode IMPORTANT
InfoSelectionLenze
Name
C007
¤
(conti
nued)
Te rmi na l
configuration
-0- -11- CW/CCW DC brake UP DOWN
-12- CW/CCW PAR UP DOWN
-13- CW/CCW QSP UP DOWN
-14- CCW/QSP CW/QSPDC brake JOG1
-15- CCW/QSP CW/QSP PAR JOG1
-16- CCW/QSP CW/QSP JOG1/2/3
-17- CCW/QSP CW/QSP PAR DC brake
-18- CCW/QSP CW/QSP PAR Trip set
-19- CCW/QSP CW/QSP DC brake Trip set
-20- CCW/QSP CW/QSP Trip set JOG1
-21- CCW/QSP CW/QSP UP DOWN
-22- CCW/QSP CW/QSP UP JOG1
-2 3- M/ R CW/ CCW UP DOWN
-24- M/R PAR UP DOWN
-25- M/R DC brake UP DOWN
-26- M/R JOG1 UP DOWN
-27- M/R Trip set UP DOWN
-28- JOG1/2/3 I-OFF D/F
-29- JOG1 DC brake I-OFF D/F
-30- JOG1 QSP I-OFF D/F
-31- DC brake QSP I-OFF D/F
-32- Trip set QSP I-OFF D/F
-33- QSP PAR I-OFF D/F
-34- CW/QSP CCW/QSP I-OFF D/F
-35- JOG1/2/3 PAR D/F
-36- DC brake QSP PAR D/F
-37- JOG1 QSP PAR D/F
-38- JOG1 PAR Trip set D/F
-39- JOG1/2/3 Trip set D/F
-40- JOG1 QSP Trip set D/F
-41- JOG1 DC brake Trip set D/F
-42- QSP DC brake Trip set D/F
-43- CW/CCW QSP Trip set D/F
-44- UP DOWN PAR D/F
-45- CW/CCW QSP PAR D/F
-46- M/R PAR QSP JOG1
-47- CW/QSP CCW/QSP M/R JOG1
-48- INFL_0 DC brake I-OFF D/F
-49- INFL_0 JOG1 QSP D/F
-50- INFL_0 JOG1 I-OFF D/F
-51- DC brake PAR I-OFF D/F
- Tri p- Se t =
External fault
- UP/ DOWN =
Motor
potentiometer
functions
- H/Re =
Manual/Remot
e changeover
- I-OFF =
Rese t
I-component of
the PID
controller
- D/F =
Digital
frequency
input 0 - 10
kHz
- INFL_0 =
Set influence
of the PID
controller to 0
When changing
between the
parameter sets
via terminal, the
corresponding
terminal must be
assigned with
PAR in both
parameter sets.
