Configuration
7-15
 SHB9300CRV EN 2.0
5. The entries under C0465 are:
– Pos. 10: AND1 10500
– Pos. 11: OR1 10550
– Pos. 12: AND2 10505
This example started with position 10 because the factory setting is not assigned to any of these
positions.
FBs need not to be entered into the processing table one after the other. The processing table
tolerates unassigned positions.
Note!
It is also possible to enter FBs different from the FBs indicated in the example.
FBs, which do not have to be entered into the processing table
The following signal sources are always executed and need not to be entered into the processing
table:
- AIF-IN
- CANx-IN
- DIGIN
- DIGOUT
- FCODE (all free codes)
- MCTRL
- Fixed signal sources (FIXED0, FIXED0%, etc.)
Frequent configuration faults
Faulty operation Cause Remedy
FB does not set an output signal FB was not entered into the processing table
C0465
Enter FB
FB indicates constant signals only FB has been overwritten or deleted from the
processing table C0465
Enter FB again, if necessary using a different
subcode (list position)
The output signal is not send to the next FB No connection between the FBs Create connection (following FBs) via the
configuration code (CFG)
FB cannot be entered into table C0465 Not enough remaining processing time (see
C0466)
If necessary, delecte all FBs not used (e.g.
inputs and outputs not used)
With DC-bus operation it might be possible to
execute some functions via other controllers
The controller delays the transfer of internally
calculated signal to the outputs.
The processing sequence for the FBs is wrong. Adapt the processing table to the signal flow
(C0465).
