Lenze EVS9323-EK User Manual

Configuration
7-277

SHB9300CRV EN 2.0
Global Drive Control or LEMOC29371BB keypad
SubmenuMain menuSubmenuMain menu
PCTRL PCTRL Process controller
PHADD1 PHADD1 32 bit addition element
PHCMP1 PHCMP1 Phase comparator
PHCMP2 PHCMP2 Phase comparator
PHCMP3 PHCMP3 Phase comparator
PHDIFF1 PHDIFF1 32 bit setpoint/act. value comparison
PHDIV1 PHDIV1 Phase division
PHINT1 PHINT1 Phase integrator
PHINT2 PHINT2 Phase integrator
PHINT3 PHINT3 Phase integrator
PT1 PT1 Delay element
R/L/Q R/L/Q CW/CCW/QSP
REF REF Homing
RFG RFG Ramp function generator
SRFG1 SRFG1 S-shape ramp function generator
STORE1 STORE1 Store phase, E5
STORE2 STORE2 Store phase, E4
SYNC1 SYNC1 Control program synchronization
TRANS1 TRANS1 Transition evaluation
TRANS2 TRANS2 Transition evaluation
TRANS3 TRANS3 Transition evaluation
TRANS4 TRANS4 Transition evaluation
FCODE Free codes
Identify Identification
Drive Controller
Op keypad LECOM
